MOPX 205 Alfa Laval Oil Purifiers are used in marine installations and power stations. It is designed for the automatic non-continuous discharge of separated sludge. It is suitable for all types of onboard marine applications.
MOPX 205 is operated with an EPC-41 electronic control unit which has a built-in PI temperature controller for fuel oil heater. It has a self-cleaning bowl which can be either used as clarifier or purifier. GumaTech offers MOPX Purifiers in the fully reconditioned state.
Features:
- It has a maximum rated capacity of 4900 LPH
- Process temperature is min/max 0/100°C
- Maximum density of feed is 1100 kg/m3
- Maximum density of sediment is 2362 kg/m3
- It uses EPC 41 control panel
- It has a 3 phase electric motor of 4 kW
- Maximum bowl speed is 7537 RPM
- Speed of motor shaft is 1800 RPM
- Maximum density of an operating liquid is 1000 kg/m3
